BCS Hay Rake Attachment 125cm Steering Arm
No reviews
The hay rake is a fantastic tool for rowing-up meadow grass and wildflowers, especially after using the scythe and saves huge amounts of time over hand raking.
Please note: This is the implement only.
SKU: MOD 145/1 SA
HURRY! ONLY LEFT IN STOCK.
Description
Manufactured by Repossi Macchine Agricole srl, there are two sizes of hay rake available – the MOD 120/1 with a 105cm working width and the MOD 145/1 with a 125cm working width.
The hay rake offers a very efficient method of not only rowing-up, but also turning over cut material to prevent it from rotting and enabling it to dry.
The MOD 145/1 has a belt fitted with 8 sets of 4-tooth combs which sweep the grass up and over and into rows. The raked material can then be easily baled or removed with the buck rake or fork once it is rowed.
The width and position of the rows is controlled by the adjustable arm located at the side of the hay rake.
This model, the MOD 145/1 has a steering arm for manoeuvrability during operation and is best suited to the power units without steering brakes.
For larger machines such as the BCS 630WS and 660HY we recommend the MOD 145/1 with castor wheels.
Specifications
Weight
75kg
Dimensions (L x W x H)
145cm overall width
Warranty
2 years
Working Width
125cm (49")
Steering Mechanism
Steering Arm
Max. Working Speed
5km/hr
The Hay Rake 125cm (Steering Arm) will fit the following products:
BCS 618 Power Scythe
From £3,490.00
BCS 630 Power Scythe
From £4,540.00
BCS 738 Two Wheel Tractor
From £2,995.00
BCS 740 Two Wheel Tractor
From £3,495.00
BCS 750 Two Wheel Tractor
From £4,075.00
BCS 780HY Two Wheel Tractor
From £4,745.00
BCS 738 Rotavator (C10)
From £3,780.00
BCS 740 Rotavator (C13)
From £4,280.00
BCS 750 Rotavator (C15)
From £5,420.00
BCS 780HY Hydrostatic Rotavator (C18)
From £4,745.00
BCS 740F Professional Flail Mower
From £5,490.00
BCS 780HY Hydrostatic Flail Mower
From £6,740.00
Downloads
Parts Diagram
Operating Manual
Brochure
